Flexible Hoses

料號 尺寸 (Dimension in mm)
MH-KF-16-250L
Flange Size: KF16
Length: 250
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
KF1626.720.10.153.2250
MH-KF-16-500L
Flange Size: KF16
Length: 500
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
KF1626.720.10.153.2500
MH-KF-16-1000L
Flange Size: KF16
Length: 1000
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
KF1626.720.10.153.21000
MH-KF-25-250L
Flange Size: KF25
Length: 250
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
KF253325.10.154.2250
MH-KF-25-500L
Flange Size: KF25
Length: 500
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
KF253325.10.154.2500
MH-KF-25-1000L
Flange Size: KF25
Length: 1000
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
KF253325.10.154.21000
MH-KF-40-250L
Flange Size: KF40
Length: 250
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
KF4049.437.90.25.2250
MH-KF-40-500L
Flange Size: KF40
Length: 500
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
KF4049.437.90.25.2500
MH-KF-40-1000L
Flange Size: KF40
Length: 1000
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
KF4049.437.90.25.21000
MH-KF-50-250L
Flange Size: KF50
Length: 250
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
KF5062.7500.25.5250
MH-KF-50-500L
Flange Size: KF50
Length: 500
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
KF5062.7500.25.5500
MH-KF-50-1000L
Flange Size: KF50
Length: 1000
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
KF5062.7500.25.51000
MH-ISOK-63-250L
Flange Size: ISO-K 63
Length: 250
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
ISO638165.20.27.1250
MH-ISOK-63-500L
Flange Size: ISO-K 63
Length: 500
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
ISO638165.20.27.1500
MH-ISOK-63-1000L
Flange Size: ISO-K 63
Length: 1000
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
ISO638165.20.27.11000
MH-ISOK-80-250L
Flange Size: ISO-K 80
Length: 250
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
ISO801271000.210250
MH-ISOK-80-500L
Flange Size: ISO-K 80
Length: 500
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
ISO801271000.210500
MH-ISOK-80-1000L
Flange Size: ISO-K 80
Length: 1000
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
ISO801271000.2101000
MH-ISOK-100-250L
Flange Size: ISO-K 100
Length: 250
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
ISO10096780.27.5250
MH-ISOK-100-500L
Flange Size: ISO-K 100
Length: 500
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
ISO10096780.27.5500
MH-ISOK-100-1000L
Flange Size: ISO-K 100
Length: 1000
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
ISO10096780.27.51000
MH-ISOK-160-250L
Flange Size: ISO-K 160
Length: 250
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
ISO160175.5149.50.256.5250
MH-ISOK-160-500L
Flange Size: ISO-K 160
Length: 500
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
ISO160175.5149.50.256.5500
MH-ISOK-160-1000L
Flange Size: ISO-K 160
Length: 1000
Flange SizeID (mm)OD (mm)Wall Thickness (mm)PitchL
ISO160175.5149.50.256.51000
