圖片 CF 6-way Crosses

CF 6-way Crosses

Flange Size

料號尺寸 (Dimension in mm)

料號:

Flange Size: CF1.33" (DN16)

A
38.1

料號:

Flange Size: CF2.12" (DN25)

A
52.07

料號:

Flange Size: CF2.75" (DN40)

A
62.48

料號:

Flange Size: CF3.38" (DN50)

A
81.79

料號:

Flange Size: CF4.50" (DN63)

A
85.85

料號:

Flange Size: CF4.62" (DN80)

A
92.2

料號:

Flange Size: CF6.00" (DN100)

A
134.9
